The ECLIPSE M suppressor is the result of 6 years of development in collaboration with the Norwegian Armed Forces and the Norwegian Defence Research Establishment (FFI). The primary objective of the project has been to construct a suppressor with the lowest possible signature, with a particular emphasis on flash reduction.
The suppressor has primarily been tested with the 7.62x51 caliber using the HK417 weapon system.
Based on FFI’s tests, the Eclipse M was selected as the suppressor for the Norwegian Armed Forces. It is now a standard product for the Norwegian Armed Forces and is included in the NATO database with the following NSN number:
NSN: 1005-25-163-2857
ECLIPSE • M
Eclipse • M is our suppressor developed for the 7,62x51 caliber, where the main focus has been to reduce thetotal signature of the weapon. The suppressor is delivered with a flash hider, which will be permanently attached to the barrel.
Added length
176mm
Total length
230mm
Diameter
47mm
Weight
436g + 52g
Performance – 308W
34-39 dBC
Calibers
.30
THE SOUND
of SILENCE
TITAN 5
Titanium Core
Extremely light and robust baffle core. Giving the suppressor a very long lifetime.
TITAN 5
Blast baffle
Increased strength and thickness for handling high pressure and temperature.
TITAN 5
Blast chamber
Strong construction dividing the gas evenly in the chamber.
TITAN 5
Chamber-wall
Parabolic construction for increased strength.
TITAN 9
Outer-tube
Superlight and strong titanium tube, designed for handling high pressure.
17-4 PH
Muzzle break
or Flash-hiderVery efficient muzzle brake and flash-hider.
INCONEL
Core optimizer
Unique technology that balances pressure and temperature while shooting.
ECLIPSE • MB
Eclipse • MB is our suppressor developed for the .338 Lapua Magnum and similar calibers, where the main focus has been to reduce the total signature of the weapon. This model is also available in caliber 30. The suppressor is delivered with an efficient muzzle brake, which will be permanently attached to the barrel.
Added length
176mm
Total length
230mm
Diameter
47mm
Weight
436g + 52g
Performance – 308W
34-39 dBC
Performance – 338 LM
30-34 dBC
Calibers
.30 and .388
Soldiers have a significant need to remain concealed during missions. The flash from the weapon system during firing acts as a marker that reveals the soldier’s position to the enemy. Minimizing this as much as possible is crucial for ensuring the soldier’s safety and enhancing the likelihood of mission success.
The first shot consistently produces a larger flash compared to the subsequent shots, which is a significant problem with most suppressor models available on the market.
With the ECLIPSE M - Suppressor, this issue is addressed by providing close to zero flash signature on the first shot and no visible flash on subsequent shots. This has been documented through photon measurements by FFI, following the STANREC 4785 test procedures.
